Yellow Striped Waistcoat

(Before I get to the waistcoat I'd like to ask - does anyone know how to make links to an old blogger url redirect to a new one? Is it possible to do that? I really don't like my url, and I want to change it, but I also really don't want to break nearly 7 years of links.)

I made another waistcoat! I finished this one on September 22nd and am mostly happy with how it turned out, though the wrinkled shoulders do vex me.
It's made from a striped silk taffeta I bought in Ottawa in the spring of 2018 (on a road trip that I still need to post about...). It's the same stuff I used for part of the lining of my bright green waistcoat.
I'd only made two collared late 18th century waistcoats before and wasn't happy with the fit of either of them, so I drafted a new pattern for this one. It's better but I still need to tweak it a bit.
I'm currently working on an embroidered waistcoat that's the same pattern shape, so this one was sort of a trial run, since I hadn't sewn one of these with historically accurate construction methods before.
Those other two waistcoats both have little vents in the back and side seams, but most of the extant waistcoats with this cut don't have those, so I made this one closed all around on the bottom edge. I based the pattern somewhat on the one in The Cut of Men's Clothes, but I had to make mine much curvier to fit around my hips.

I pieced the back out of 6 scraps of brown linen. One of these seams is two selvedges butted together and whipstitched, because this linen had nice firm selvedges. You can just barely see it on the left side of this photo.
(I also pieced a little bit of different linen to the topmost corner of each of the silk fronts, to make the cutting layout more efficient. This was not at all necessary, I just really like piecing and saving on fabric.)
All the seams in this photo are hand sewn, just because.
For the buckram interfacing I stiffened some cotton muslin. The lining is a pale green cotton sateen that I got at the fabric swap in January.
I hadn't done waistcoat pocket welts using the 18th century method before, but it turned out to be very easy. As with with bigger pocket flaps, you line them first and then just stick them on.
My welts. I folded the edges in around the buckram and
hand stitched the lining on the back.
The pocket bags are the same green cotton as the lining, and the openings are reinforced with another bit of buckram.
There are only 3 machine sewn seams in this waistcoat - the pocket bags and the centre back of the lining.
I cut a slit, turned back the edges, and whipstitched the pockets in.

Attaching the pocket welt.
It's so much easier to line up stripes this way!

For the collar I used two pieces of silk for the front edge, and another scrap of linen for the centre back. I folded the edges in around a piece of buckram and lined the collar in 6 silk scraps.
I hand sewed all the scraps on one at a time.

The inside of the finished collar.
I cut little facing bits for the lapels and stitched them down to the green cotton lining.

The one other time I made a waistcoat with these little lapels I was very confused as to how they were stiffened, but I have since obtained a copy of Costume Close Up, and learned that the lapels aren't stiffened at all! The buckram on this style of waistcoat stops just above where the buttons end.

I wasn't sure how exactly the buckram was supposed to be attached with this sort of waistcoat, so I tried tacking it to the lining this time instead. It worked well enough but I don't think I'll do it that way again, as it made the lining a little bit awkward to sew in along the front edge.
Front lining with the buckram about to be stitched into place.
As far as I can tell from photos, I think the front lining is sewn on just the same as it is on earlier waistcoats, but a bit more carefully around the lapel. I used off-white silk thread for this.
It was a bit fussy to press the edges in so the lining and outer fabric were the same size.
Edges all pressed in and lined up nicely.

I sewed the lapels carefully, with tiny stitches.
The rest of the edge was done with le point a rabattre sous la main, as usual.
I was so economical with my cutting and piecing that I didn't have enough scraps to cover my buttons. There were a few more little ones that hadn't made it into the collar lining, but I ruined those with a lot of pen markings doing samples for another thing, and they probably wouldn't have been sufficient to cover all 8 buttons anyway.

I could easily have cut button covers from my remaining yardage (I have about a meter and a half left) but I decided to try teeny tiny matching deaths head buttons instead. I used the second smallest bone moulds from Burnley & Trowbridge, and the finished buttons are about 12mm.
I covered them with fine linen yarn from my mothers stash, in off-white and pale yellow.
They were quick to cover, and not difficult to do, but holding onto them did cause some finger cramps.
My tiny buttons with subtle X's on them.
I think I was inspired by the little deaths head buttons that appear on several of the waistcoats in Waistcoats From the Hopkins Collection.
The waistcoat on this page was dated c. 1800-1805, but there were very similar buttons on an earlier waistcoat.
I sewed the buttonholes through all the layers, after lining the fronts. I felt like this made more sense for this style of waistcoat than the usual earlier method, and photos of the inside of two different waistcoats from the aforementioned book show buttonholes sewn through all the layers.
They're sewn by hand with yellow DMC cotton pearl.

The outside of the fronts.

And the inside.


I backstitched the side and shoulder seams with linen thread.
I pinned the collar in place, basted it in with a running stitch just to be sure it was sitting correctly, and then backstitched it in.
I folded the neckhole bit of the front lining carefully over the collar seam, stitched it down, and popped in the back lining last, as usual.

Finished! In pretty good time too. I can't remember exactly when I started it but I think I did it within the space of about 3 or 4 weeks.



That slight wobbliness along the front edge is why I'm not
going to try tacking the interfacing to the lining again.
I hadn't started this with the Historical Sew Monthly in mind, but seeing as it's fairly plain I decided it worked for September's "Everyday" theme.


What the item is: A man’s waistcoat

How it fits the challenge: It’s pretty plain and informal, and I do intend to wear it for everyday.

Material: Silk taffeta striped in dull yellow, beige, and off white, brown linen for the back, pale green cotton sateen for the lining, and two different silk scraps that were used in the collar lining.

Pattern: My own, based mostly on photos of extant originals.

Year: c. 1785-95

Notions: Eight 11mm bone button moulds, muslin I made buckram from, DMC cotton pearl for the buttonholes, silk thread, linen thread, fine linen yarn.

How historically accurate is it? Pretty good! It’s hand sewn except for 3 seams (the pocket bags, and the CB seam of the lining), I think I got the cut pretty good, and the materials are mostly accurate except for the lining. All the piecing makes it more historical too.

Hours to complete: 25:19 - less than I expected!

First worn: September 22nd, 2019

Total cost: I bought the button blanks, the silk, and some of the thread. The lining was from a fabric swap and everything else was given to me. I used so little of the silk that I doubt the whole thing came to any more than $20 Canadian.
I took these photos with a self timer in the old house I was doing an artist residency in last month. It was a nice, quiet time and I got a lot done on the embroidered waistcoat I mentioned earlier.
I will have to make some changes to this pattern before I sew it up again, particularly the shoulders. Since I drafted a whole new pattern mainly because I was annoyed by the wrinkled shoulders of my previous waistcoats, it was disappointing to have them turn out wrinkly again.
I think I need to scoop out the side of the neckhole a bit more, and to not make the shoulder seam straight. It ought to fit the shape of my shoulders better, I think. Next time I should try adding a little triangle insert piece like you see on so many extant waistcoats. I'll also change the centre back of the collar so it's tapered just a little more, as I think it sticks out from my neck the tiniest bit too much.

Here it is with a coat I finished in August but still haven't blogged about yet.
But I just got some good photos of the coat this weekend, so I will post about it soon!

(I am now working on the waistcoat for my 1730's suit, but still haven't started the breeches.)

Friday, 26 July 2019

Green Wool 1730's Coat

The 30's coat is done! It's been done since June 30th but I have been rather slow in getting all these photos organized.
This is the first time I've made a coat with the proper 18th century construction techniques, and I wanted to go over it all quite thoroughly. There are some things I would do differently, but overall I'm very pleased with how it turned out!
This is one of the most time consuming things I've ever sewn, clocking in at just over 100 hours. Nearly half of that time was spent on the buttonholes & buttons.

In my earlier post on this coat I talked about the pattern, and puzzled a bit about some of the construction details. This post is mostly about the construction and there are a lot of pictures.

I haven't got any Fancy photos of me wearing the coat yet because I don't have proper 1730's breeches to go with it, nor a 30's waistcoat that actually fits correctly and is the right length. (And it's July, which is not a great time to wear wool coats.)

So! Construction. I made some buckram with black linen, and also slightly stiffened some patterned cotton canvas for the front skirts. It's not as stiff as the buckram, but since the canvas had been washed I wanted to make it a bit more crisp. I cut out a little bit of padding just like the one in the Cut Of Men's Clothes diagram in my previous post.
All my interfacing bits
I tacked all the buckram in place.
Cut the pocket hole open in that triangular shape you see on extant coats & waistcoats, and tacked the quilt batting on too.
I sewed both halves of the pocket bag together by machine and stitched it to the opening by hand.
I pressed all the front edges inwards and stitched them down too.
This is the place where the functional buttons at the waist are attached
so I added an extra bit of buckram.
I did the same on the back skirts. Buckram on the centre back edge, and quilt batting on the part that makes up the side pleats. Before this, though, I had to sew in the extra skirt panel in the centre back (you can see in in the pattern in my previous post). I did most of the long edge by machine and finished up the short edge on top by hand.
Now it was time for buttonholes. So many buttonholes. I knew I wanted to have some cord in them to make them a bit thicker, and I did some samples to see what I liked best.
I looked around the house for a suitable bit of cord, but everything that was the right size was either too soft & squishy or too bumpy. I settled on a smaller cord which I waxed and braided to make it the right size.
I marked out the locations of all 79 buttonholes. 27 down the front, 4 on each pocket flap, 5 on each cuff, and 17 down each side of the centre back split.
They're each 6.5 cm long, with the exception of the ones in the middle of the pocket flaps, which are slightly longer.
I decided the nicest way to hide the ends of the cords would be to poke a hole with an awl and stick the end of the cord down through it. So I did that, and stitched the cords down.
After doing my sample I settled on just covering the cord with smooth stitches going round and round, but after I was halfway done doing the ones down the centre back slit I changed my mind, so the back ones are smooth and the rest of them are all done with buttonhole stitches.

I did only one row of buttonhole stitches on the false ones. I know some extant coats have false ones with 2 rows, but I really didn't want to spend nearly twice as much time sewing 79 buttonholes. Just doing them with one line of buttonhole stitches took an eternity.
Here are the smooth ones I did down the back:
Here's one partly done with buttonhole stitches once I changed my mind:
I had foolishly lined the cuffs and pocket flaps already, so I had to pick the lining off most of the way around and re-sew it after doing the buttonholes. That's ok though, I really like putting on linings.

I also realized later that it was better to couch down the whole cord instead of awkwardly stabbing it on like I had been doing.
For the 6 functional buttonholes I also put a bit of cord around the edge to make them a bit more sturdy. It's the same cord as in the false buttonholes, but not braided.
Functional buttonhole being sewn.

1 - buttonhole cut
2- overcast
3 & 4 - cord added
5 - buttonhole stitches done.
(6 is a false one with just the cord couched down)
I had not taken the chest padding into consideration, and found it rather troublesome to sew through. Next time I will know to add it after the buttonholes!
I covered 47 5/8" wooden button moulds. I sewed the buttons on in all the necessary places. (Except for the last two that go over the back pleats.) I sewed the pocket flap in place around the same time too.

Finished cuff with buttons!
As I decided to do in my previous post, I overlapped the edges of the cuff and the sleeve end and whipstitched them down. The sleeve, at this point, had already been lined. I sewed the long seams by machine and hand stitched the lining down around the cuff opening.





Lining being put on the cuff.
I pieced together the lining in a few places. I didn't need to, I had enough fabric to cut out all the pieces whole, but I wanted to be more economical with it.
The upper back lining is brown linen and everything else is a cotton/silk blend satin.
I put the front and back skirt linings in the usual way, with le point a rabattre sur le main.
Now all the pieces were finally lined and ready to be assembled! At this point the only raw edges are at the side, upper back, and shoulder seams, and the armholes.
Outside of the lined pieces.

Inside of the lined pieces. As you can see, the back lining isn't attached yet.

Pocket flap!

Originally when I did the lining around the functional buttonholes I did it my usual way, with the lining slashed and turned under, but it looked very bad. Due to a combination of the fabric being thick and prone to fraying, and the buttonholes being quite long, it was a horrible hideous mess that I didn't even photograph.
So I cut that whole chunk of lining out and re-did it with the method I should have used in the first place. By piecing little rectangular bits in between them all, allowing the lining edges to be folded down nice and flush against all the buttonhole edges. I can't seem to find a photo of this on the internet at the moment but I know it can be found on some extant garments. Waistcoats From The Hopkins Collection has a nice early 18th century example on page 13.
Thankfully I hadn't gotten as far as the one functional buttonhole on the top before I changed methods, so I didn't have to replace the lining on both edges.
Just had to add one little bit.
You can also see some of the aforementioned lining piecing on the shoulder.
Here are the finished functional buttonholes from the outside:
Only 5 of them, right at the waist.
Plus one more at the very top.
I sewed the centre back seam with a backstitch.
And after pressing it open I sewed the side seams with a backstitch too. It seemed reasonable that the lining should not get in the way of putting the sleeve in, so I caught the lining in the side seam for most of the way up, but made sure not to for the top 5 or 6 cm.
Side seams sewn.
I did the same for the shoulder seams. I tried the coat on at this point, just to make extra sure it fit, which it did.
I basted the sleeves in and then sewed them in with a backstitch. All the seam allowances from the sleeve and coat body get pressed inwards towards the shoulder.
(This is one of the few things that Costume Close Up isn't super clear on, but judging from the sloping shoulder look that you see in every portrait and on every extant coat it seemed the only place for the seam allowances to go.)
I basted the lining down so it'd sit in the correct place.
I also did a bit of a prickstitch on the outside of the armscye, because I was worried the seam allowances wouldn't stay in place well enough on their own.
I folded down the front lining around the armhole and stitched it down. I'm not 100% satisfied with how the armscyes look on close inspection because I think I eased a tiny bit too much cloth from the top of the sleeve into it. Not enough so that it's puffy or anything, but it's not quite as smooth as the ones on extant coats.
It also didn't occur to me until later that maybe I should have added some extra bits of linen for structure and support into these seams. There's a bit of wrinkling, particularly around the left armscye, but it's not too bad.
It's hard figuring out 18th century tailoring all by yourself, and I'm very envious of people who get to go learn from professionals at places like Williamsburg!
Making the back skirt lining end a bit above the waist instead of right at it is another thing I should have done. I hadn't considered exactly how the back lining would go in with the back pleats in the way, so it got a bit messy.

Wrangling the back pleats into shape was probably the most difficult part of construction. There's so much material there! I then sewed the last 2 buttons on, right over the tops of the back pleats.
Back pleats all tacked together. I added a bit more stitching to them after taking this photo.
I popped in the back lining and sewed all the edges down, finishing up all those raw edges.
Had I sufficient foresight to make the skirt lining higher it might have looked more like this:
Back lining of a man's silk satin coat, c. 1780's.
But instead it looks like this, which isn't particularly bad, just a bit bumpy.
Back lining all in.
In order to keep the cuff in place I stuck the top edge of it to the sleeve with some careful running stitches, something like the cuff here:
Coat c. 1730's, V&A.

Cuff secured and not prone to flopping down anymore.
And it was finally finished!

The back pleats didn't turn out poofy like I hoped they would in my first post, but that's ok because they turned out looking just like these ones.
John Smibert, William Browne, c.1734.
I may need to add some of those long thread bar tack thingies because the pleats could stand to sit a little bit better than they do. I wish more museums posted pictures of the insides of things!

I finished the coat just in time for the June Historical Sew Monthly challenge!

The Challenge: June: Favourite Technique

What the item is: A man's wool coat

Which favourite technique does it feature? I'm bad at choosing favourites, but two that are very high on my list are le point a rabattre sous la main, and piecing to economize on fabric. I had to piece the wool to squeeze such a full coat out of it, and I pieced the lining just because I wanted to be less wasteful with the cutting. I also really love the way 18th century coats & waistcoats are assembled, and how different it is from modern sewing, and how much easier it is to do it that way when you're hand sewing most of it. This is the first time I've done a coat this way.

Material: 2.8 m of green wool, 2.8 m of cotton/silk blend satin, a bit of brown linen for the back lining.

Pattern: My own, based on two of the ones from The Cut Of Men's Clothes

Year: 1730's

Notions: 47 wooden button blanks, linen thread, a tiny bit of polyester thread, DMC cotton pearl, some sort of cord (maybe linen?) that I put in the buttonholes, linen buckram, cotton canvas, cotton quilt batting.

How historically accurate is it? Maybe 85-90%? Aside from a little bit of machine sewing and a couple of things I'd do a bit differently the construction is as accurate as I could get it.

Hours to complete: 100 hours and 33 minutes. Of that time, 39:56 of it was spent on the 79 buttonholes, and 7:32 on the 47 buttons. (That hundred hours doesn't include drafting & mocking up the pattern.)

First worn: Sunday June 30th, 2019

Total cost: I'm guessing somewhere around $50 Canadian. It would have been much more if I'd bought the wool, rather than tragically inherited it. The interfacing and padding was all stuff that was given to me.
I'll get Good Fancy photos eventually, once the weather stops being horrible and sweaty.
Amazingly, the day I finished it had very nice 17 degree weather and I was able to get photos of me wearing it outside.
I didn't tack down the tops of the cuffs until after I'd taken these photos, oops.

Hopefully I'll finish the waistcoat and breeches to go with it by this autumn!
